VICOR

Vicor电源模块

Vicor详细产品资料请点击：http://www.eie-ic.com/vicor.html

VI BRICK™ Intermediate Bus Converters »	V•I Chip™ PRM / VTM »	VI BRICK™ PRM / VTM »	V•I Chip™ BCM »	Cool- Power® »	VI BRICK™ BCM »	VI BRICK™ DC-DC Converters »	Maxi, Mini, Micro Converters »	VI-200 / VI-J00 Converters »

Industry Standard Eighth and Quarter Bricks High Efficiency: >98% High Density: 255 W/in²	High Efficiency and High Power Density	High Efficiency and Thermally Enhanced	High Efficiency and High Power Density	Very High Power Density	High Efficiency and Thermally Enhanced	High Current Models	High Power Broad Vout Trim Range	Broad Selection and Current Source Module
Selection and Simulation Tool »	Select & Buy PRM » Select & Buy VTM »	Select & Buy PRM » Select & Buy VTM »	Select & Buy »		Select & Buy »	Select & Buy »	Select & Buy »	Select & Buy »
Data Sheets »	Family Data Sheet »	Whole Family PRM + VTM Shortform »	Family Data Sheet »	Choose Data Sheet »	Family Data Sheet »	Family Data Sheet »	Family Data Sheets »	VI-200/VE-200 Datasheet » VI-J00/VE-J00 Datasheet » BatMOD Data Sheet »
38 – 55 Vdc 36 – 60 Vdc	18 – 75 Vdc Four Input Ranges	18 – 75 Vdc Four Input Ranges	38 – 55 Vdc / 330 – 400 Vdc Four Input Ranges	36 - 75 18 - 36 41 - 57 Vdc	38 – 55 Vdc / 330 – 400 Vdc Four Input Ranges	36 – 75 Vdc One Input Range	9 – 425 Vdc Eight Input Ranges	10 – 400 Vdc Twelve Input Ranges
4:1 and 5:1 fixed ratio 12 and 9.6 V at 48 Vin	1.19 – 55 Vdc	0.82 – 55 Vdc	1.2 – 55 Vdc	3.3 Vdc 12 Vdc 18 Vdc	1 – 48 V	1 – 48 Vdc	2 – 54 Vdc	2 – 95 Vdc
300 – 850 W	120 – 500 W	120 – 320 W	120 – 325 W	10 – 60 W	135 – 325 W	100 – 220 W	50 – 600 W	25 – 200 W
Eighth Brick, Open Frame 2.30" x 0.9" x 0.38" (58,4 x 22,9 x 9,53 mm) Quarter Brick, Open Frame 2.30" x 1.45" x 0.41" (58,4 x 36,8 x 10,5 mm)	Full Chip 1.28" x 0.87" x 0.265" (32,5 x 22,0 x 6,73 mm) Half Chip 0.87" x 0.65" x 0.265" (22,0 x 16,5 x 6,73 mm)	Full Size Flanged 1.91" x 1.09" x 0.37" (48,6 x 27,7 x 9,5 mm)	Full Chip 1.28" x 0.87" x 0.265" (32,5 x 22,0 x 6,73 mm) Half Chip 0.87" x 0.65" x 0.265" (22,0 x 16,5 x 6,73 mm)	Power System in Package (PSIP) 0.87" x 0.65" x 0.26" (22,0 x 16,5 x 6,73 mm)	Full Size Flanged 1.91" x 1.09" x 0.37" (48,6 x 27,7 x 9,5 mm)	Flanged baseplate (Height above board) 2.19" x 1.91" x 0.37" (55,7 x 48,6 x 9,5 mm)	Maxi (Full Brick) 4.6" x 2.2" x 0.5’’ (117 x 55,9 mm) Mini (1/2 Brick) 2.28" x 2.2" x 0.5’’ (57,9 x 55,9 mm) Micro (1/4 Brick) 2.28" x 1.45" x 0.5’’ (57,9 x 36,8 mm)	VI-200 (Full Brick): 4.6" x 2.4" x 0.5" (116,9 x 61,0 x 12,7 mm) VI-J00 (Half Brick): 2.28" x 2.4" x 0.5" (57,9 x 61,0 x 12,7 mm)
Through Hole	SMT or Through Hole Half Chip only SMT	Through Hole	SMT or Through Hole Half Chip only SMT	SMT	Through Hole	Through Hole	Through Hole	Through Hole

VICOR 详细介绍
