TADIRAN
TADIRAN

TADIRAN是一家电池制造商，主要(非可充电的)锂电池。
TADIRAN公司成立1984年，TADIRAN是一家锂电池的发展为工业使用。其锂亚硫酰氯(LTC)技术已经超过30年了。3.6伏特高能原电池长达25年的时间。
TADIRAN SL-300系列
Type Terminations Size Nominal
voltage		 Nominal
capacity		 Nominal
current		 Max. continuous Temperature
range		 Dimensions in mm
SL-350 /S /T /P /PR /PT 1/2AA 3,6 V 1,2 Ah 0,6 mA 6 mA –55...+85 °C 14,5 × 25
SL-360 /S /T /P /PR /PT AA 3,6 V 2,4 Ah 2 mA 20 mA –55...+85 °C 14,5 × 50
SL-361 /S /T /P /PR /PT 2/3AA 3,6 V 1,6 Ah 1 mA 10 mA –55...+85 °C 14,5 × 33
TADIRAN SL-300系列
Type Terminations Size Nominal
voltage		 Nominal
capacity		 Nominal
current		 Max. continuous Temperature
range		 Dimensions in mm
SL-550 /S /T /P /PR /PT 1/2AA 3,6 V 0,8 Ah 0,6 mA 6 mA –55...+130 °C 14,5 × 25
SL-560 /S /T /P /PR /PT AA 3,6 V 1,7 Ah 2 mA 20 mA –55...+130 °C 14,5 × 50
SL-561 /S /T /P /PR /PT 2/3AA 3,6 V 1,0 Ah 1 mA 10 mA –55...+130 °C 14,5 × 33
TADIRAN SL-700 / SL-2700系列
Type Terminations Size Nominal
voltage		 Nominal
capacity		 Nominal
current		 Max. continuous Temperature
range		 Dimensions in mm
SL-750 /S /T /P /PR /PT 1/2AA 3,6 V 1,1 Ah 1 mA 50 mA –55...+85 °C 14,5 × 25
SL-760 /S /T /P /PR /PT AA 3,6 V 2,2 Ah 2 mA 60 mA –55...+85 °C 14,5 × 50
SL-761 /S /T /P /PR /PT 2/3AA 3,6 V 1,5 Ah 1,3 mA 75 mA –55...+85 °C 14,5 × 33
SL-2770 /S /T /P C 3,6 V 8,5 Ah 3 mA 230 mA –55...+85 °C 26 × 50
SL-2780 /S /T /P D 3,6 V 19 Ah 4 mA 340 mA –55...+85 °C 33 × 60
SL-2790 /S /T DD 3,6 V 35 Ah 10 mA 450 mA –55...+85 °C 33 × 123
TADIRAN SL-800 / SL-2800系列
Type Terminations Size Nominal
voltage		 Nominal
capacity		 Nominal
current		 Max. continuous Temperature
range		 Dimensions in mm
SL-840 /P BEL 3,6 V 0,42 Ah 0,5 mA 5 mA –55...+85 °C 18,5 × 7
SL-850 /S /T /P /PR /PT 1/2AA 3,6 V 1,2 Ah 0,5 mA 20 mA –55...+85 °C 14,5 × 25
SL-860 /S /T /P /PR /PT AA 3,6 V 2,4 Ah 1 mA 60 mA –55...+85 °C 14,5 × 50
SL-861 /S /T /P /PR /PT 2/3AA 3,6 V 1,6 Ah 0,5 mA 30 mA –55...+85 °C 14,5 × 33
SL-886 /P 1/6D 3,6 V 1,7 Ah 0,5 mA 10 mA –55...+85 °C 33 × 10
SL-889 /P 1/10D 3,6 V 1 Ah 0,5 mA 10 mA –55...+85 °C 33 × 6
SL-2870 /S /T /P C 3,6 V 8,5 Ah 3 mA 75 mA –55...+85 °C 26 × 50
SL-2880 /S /T /P D 3,6 V 19 Ah 4 mA 100 mA –55...+85 °C 33 × 60
iXtra Series
Model
Data Sheet		 Cell Size Ref Catalog Number Nominal Capacity
(Ah)		 Nominal Discharge Current
(mA)		 Dimensions (metric)
Diameter/Height		 Dimensions (standard)
Diameter/Height		 Available Terminations
TLL-5902 1/2 AA 15-5902-yy530 1.10 1.0 14.5/25.2 0.571/0.992 S P T TP PT PT2
TL-5955 2/3 AA 15-5955-yy500 1.50 1.3 14.5/33.5 0.571/1.139 S P T TP PT PT2
TL-5903 AA 15-5903-yy500 2.40 2.0 14.5/50.5 0.571/1.998 S P T TP PT PT2
TL-5920 C 15-5920-yy500 8.50 3.0 26.2/50.0 1.031/1.970 S T
TL-5930 D 15-5930-yy500 19.00 4.0 32.9/61.5 1.295/2.421 S T
TL-5937 DD 15-5937-yy50 35.00 10.0 32.9/124.5 1.295/4.902 S T
XOL Series
Model
Data Sheet		 Cell Size Ref Catalog Number Nominal Capacity
(Ah)		 Nominal Discharge Current
(mA)		 Dimensions (metric)
Diameter/Height		 Dimensions (standard)
Diameter/Height		 Available Terminations
TL-4902 1/2 AA 15-4902-yy000 1.20 1.0 14.5/25.2 0.571/0.992 S P T TP PT PT2
TL-4955 2/3 AA 15-4955-yy000 1.65 1.3 14.5/33.5 0.571/1.319 S P T TP PT PT2
TL-4903 AA 15-4903-yy000 2.40 2.0 14.5/50.5 0.571/1.998 S P T TP PT PT2
TL-4920 C 15-4920-yy000 8.50 3.0 26.2/50.0 1.031/1.970 S T
TL-4930 D 15-4930-yy000 19.00 4.0 32.9/61.5 1.295/2.421 S T
TLH Series Batteries
Model
Data Sheet		 Cell Size Ref Catalog Number Nominal Capacity
(Ah)		 Nominal Discharge Current
(mA)		 Dimensions (metric)
Diameter/Height		 Dimensions (standard)
Diameter/Height		 Available Terminations
TLH-5902 1/2 AA 15-5902-yy505 0.9 1.0 14. /25.2 0.571/0.992 S P T TP PT PT2
TLH-5955 2/3 AA 15-5955-yy505 1.4 1.3 14.5/33.5 0.571/1.319 S P T TP PT PT2
TLH-5903 AA 15-5903-yy505 2.0 1.0 14.5/50.5 0.571/1.998 S P T TP PT PT2
TLH-5920 C 15-5920-yy505 7.5 3.0 26.2/50.0 1.031/1.970 S T
TLH-5930 D 15-5930-yy505 17.0 5.0 32.9/61.5 1.295/2.421 S T

TADIRAN Products - data sheets PulsesPlus Batteries

TADIRAN Products - data sheets HLCs

TADIRAN Products - data sheets TLM-Batteries

TADIRAN Products - Background Information

Safety data sheets
