ARCH

ARCH电源

ARCH成立于1986年,ARCH通过iso-9001认证保证的产品质量。ARCH是专业的dc直流开关电源、医疗功率模块、交直流电源模块和直流-直流转换器。几十年的发展中,ARCH也有优秀的经历来负责OEM/ODM项目提供产品。


ARCH
AC-DC Power Module


Watts Model No. I/P Voltage O/P Voltage
2 W Series
AC IN: 90 ~ 305 VAC
DC IN: 120 ~ 430 VDC
Single: 3.3, 5, 9, 12, 15, 24


Green Power ( Low Stand-by )
Size:28.5 x 25.8 x 17.0 mm
Isolation:3000 VAC
AZC:Down Load AZC Series SPC. AZCSafety:
2 W Series
AC IN: 90 ~ 305 VAC
DC IN: 120 ~ 430 VDC
Single: 3.3, 5, 9, 12, 15, 24


Green Power ( Low Stand-by )
Size:33.7 x 22.2 x 17.0 mm
Isolation:3000 VAC
AYC:Down Load AYC Series SPC. AYCSafety:
3 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 9, 12, 15, 24


Green Power ( Low Stand-by )
Size:35.7 x 19.0 x 22.0 mm
Isolation:3750 VAC
AIC:Down Load AIC Series SPC. AICSafety:
4 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 8, 9, 12, 14, 15, 24
Dual: 5/3.3, 8/5, 12/5

Green Power ( Low Stand-by )
Size:36.66 x 27.16 x 17.1 mm
Isolation:3000 VAC
AOC:Down Load AOC Series SPC. AOCSafety:
4 W Series
AC IN: 90 ~ 305 VAC
DC IN: 120 ~ 430 VDC
Single: 3.3, 5, 8, 9, 12, 14, 15, 24
Dual: 5/3.3, 8/5, 12/5

Green Power ( Low Stand-by )
Size:36.66 x 27.16 x 17.1 mm
Isolation:3000 VAC
AOCH:Down Load AOCH Series SPC. AOCHSafety:
5 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24


Green Power ( Low Stand-by )
Size:50.8 x 25.4 x 15.16 mm
Isolation:3000 VAC
AHC:Down Load AHC Series SPC. AHCSafety:
5 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24
Dual: ±5, ±12, ±15

Economic Power
Size:55.0 x 45.0 x 20.5 mm
Isolation:3000 VAC
APC:Down Load APC Series SPC. APCSafety:
7 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24


Economic Power
Size:27.03 x 27.03 x 18.7 mm
Isolation:3000 VAC
AUC:Down Load AUC Series SPC.If you were interested in this new product, please don't be hesitated tocontact us. AUCSafety:
8 W Series
AC IN: 90 ~ 305 VAC
DC IN: 120 ~ 430 VDC
Single: 3.3, 5, 8, 9, 12, 14, 15, 24
Dual: 5/3.3, 8/5, 12/5

Economic Power
Size:37.5 x 28.0 x 27.4 mm
Isolation:3000 VAC
ALC:Down Load ALC Series SPC. ALCSafety:
8 W Series
AC IN: 90 ~ 305 VAC
DC IN: 120 ~ 430 VDC
Single: 3.3, 5, 8, 9, 12, 14, 15, 24
Dual: 5/3.3, 8/5, 12/5

Green Power ( Low Stand-by )
Size:52.2 x 26.8 x 19.0 mm
Isolation:3000 VAC
AHC08:Down Load AHC08 Series SPC. AHC08Safety:
10 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24


Economic Power
Size:52.4 x 27.2 x 23.5 mm
Isolation:3000 VAC
AFC:Down Load AFC Series SPC. AFCSafety:
10 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24
Dual: ±5, ±12, ±15

Economic Power
Size:64.0 x 45.0 x 21.5 mm
Isolation:3000 VAC
ATC:Down Load ATC Series SPC. ATCSafety:
15 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24


Economic Power
Size:38.1 x 25.4 x 19.0 mm
Isolation:4000 VAC
AVC:Down Load AVC Series SPC.If you were interested in this new product, please don't be hesitated tocontact us. AVCSafety:
15 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24


Economic Power
Size:55.0 x 45.0 x 20.5 mm
Isolation:4000 VAC
APCN:Down Load APCN Series SPC. APCNSafety:
15 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24


Economic Power
Size:64.0 x 45.0 x 21.5 mm
Isolation:4000 VAC
ATCN:Down Load ATCN Series SPC. ATCNSafety:
15 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24


Economic Power
Size:74.0 x 54.0 x 22.0 mm
Isolation:4000 VAC
ANCN:Down Load ANCN Series SPC. ANCNSafety:
15 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24
Dual: ±5, ±12, ±15
Triple: 5/±12, 5/±15
Economic Power
Size:74.0 x 54.0 x 22.0 mm
Isolation:3000 VAC
ANC A:Down Load ANC A Series SPC. ANC ASafety:
20 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24


Economic Power
Size:52.4 x 27.2 x 23.5 mm
Isolation:3000 VAC
AFC20:Down Load AFC20 Series SPC. AFC20Safety:
20 W Series
AC IN: 90 ~ 264 VAC
DC IN: 100 ~ 375 VDC
Single: 3.3, 5, 7.35, 9, 12, 15, 24
Dual: ±5, ±12, ±15
Triple: 5/±12, 5/±15
Economic Power
Size:70.0 x 48.0 x 22.0 mm
Isolation:3000 VAC
AKC:Down Load AKC Series SPC. AKCSafety:
30 W Series
AC IN: 90 ~ 305 VAC
DC IN: 120 ~ 430 VDC
Single: 3.3, 5, 12, 15, 24


Green Power ( Low Stand-by )
Size:64.0 x 45.0 x 23.5 mm
Isolation:3000 VAC
ATC30:Down Load ATC30 Series SPC. ATC30Safety:
30 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24
Dual: ±5, ±12, ±15, 5/12
Triple: 5/±12, 5/±15
Economic Power
Size:89.0 x 63.5 x 25.0 mm
Isolation:3000 VAC
ASC:Down Load ASC Series SPC. ASCSafety:
40 W Series
AC IN: 90 ~ 264 VAC
DC IN: 100 ~ 375 VDC
Single: 3.3, 5, 9, 12, 15, 24
Dual: ±5, ±12, ±15, 5/12, 5/24
Triple: 5/±12, 5/±15
Economic Power
Size:89.0 x 63.5 x 25.0 mm
Isolation:3000 VAC
AJC:Down Load AJC Series SPC. AJCSafety:
50 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24, 48


Economic Power
Size:74.0 x 54.0 x 22.0 mm
Isolation:3000 VAC
ANC50:Down Load ANC50 Series SPC. ANC50Safety:
60 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 9, 12, 15, 24, 48


Economic Power
Size:109.0 x 58.5 x 30.0 mm
Isolation:4000 VAC
AEC60:Down Load AEC60 Series SPC. AEC60Safety:
100 W Series
AC IN: 90 ~ 264 VAC
AC IN: 120 ~ 370 VDC
Single: 12, 15, 24, 48


Economic Power
Size:109.0 x 58.5 x 30.0 mm
Isolation:3000 VAC
AQC100:Down Load AQC100 Series SPC. AQC100Safety:
125 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 12, 15, 24, 48


Economic Power
Size:148.0 x 71.0 x 38.0 mm
Isolation:3000 VAC
AQC125:Down Load AQC125 Series SPC.If you were interested in this new product, please don't be hesitated tocontact us. AQC125Safety:
5 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24


Green Power ( Low Stand-by )
Size:50.8 x 25.4 x 15.16 mm
Isolation:3000 VAC
AHC-E1:Down Load AHC-E1 Series SPC. AHC-E1Safety:
5 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24
  ±5, ±12, ±15

Economic Power
Size:55.0 x 45.0 x 20.5 mm
Isolation:3000 VAC
APC-E1:Down Load APC-E1 Series SPC. APC-E1Safety:
10 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24


Economic Power
Size:52.4 x 27.2 x 23.5 mm
Isolation:3000 VAC
AFC-E1:Down Load AFC-E1 Series SPC. AFC-E1Safety:
10 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 3.3, 5, 12, 15, 24
Dual: ±5, ±12, ±15

Economic Power
Size:64.0 x 45.0 x 21.5 mm
Isolation:3000 VAC
ATC-E1:Down Load ATC-E1 Series SPC. ATC-E1Safety:
15 W Series
AC IN: 90 ~ 264 VAC
DC IN: 120 ~ 370 VDC
Single: 5, 12, 15, 24
Dual: ±5, ±12, ±15
Triple: 5/±12, 5/±15
Economic Power
Size:74.0 x 54.0 x 22.0 mm
Isolation:3000 VAC
ANC A-E1:Down Load ANC A-E1 Series SPC. ANC A-E1Safety:

DC-DC Converter ?
? ??Module Type ?
?
Watts Model No. I/P Voltage O/P Voltage ?
1.5 W ? Series
? 4.5 ~ 5.5 VDC
10.8 ~ 13.2 VDC
21.6 ~ 26.4 VDC
? 43.2 ~ 52.8 VDC
?Single: 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 10.2 mm
Isolation:500 VDC
SB1R5:Down Load SB1R5 Series SPC.? ??SB1R5?Safety:????
3 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 10.2 mm
Isolation:1600 VDC
SB03:Down Load SB03 Series SPC.? ??SB03?Safety:????
5 W ? Series
4:1 Range :? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 10.2 mm
Isolation:1600 VDC
SB05:Down Load SB05 Series SPC.? ??SB05?Safety:????
5 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 11.2 mm
Isolation:1600 VDC
SH05:Down Load SH05 Series SPC.? ??SH05?Safety:????
5 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 10.2 mm
Isolation:1600 VDC
ZA05:Down Load ZA05 Series SPC.? ??ZA05?Safety:????
5 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VD
?
?Single: 3.3, 5, 12, 15, 24
?
?
Size:31.8 x 20.3 x 10.2 mm
Isolation:1600 VDC
ZC05:Down Load ZC05 Series SPC.? ??ZC05?Safety:????
8 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 10.2 mm
Isolation:1600 VDC
SB08:Down Load SB08 Series SPC.? ??SB08?Safety:????
8 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 11.2 mm
Isolation:1600 VDC
SH08:Down Load SH08 Series SPC.? ??SH08?Safety:????
10 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:31.8 x 20.3 x 11.2 mm
Isolation:1600 VDC
SH10:Down Load SH10 Series SPC.? ??SH10?Safety:????
10 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
4:1 Range:? 10 ~ 40 VDC
18 ~ 75 VDC
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:50.1 x 25.4 x 10.8 mm
Isolation:1600 VDC
ST10:Down Load ST10 Series SPC.? ??ST10?Safety:????
15 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15
?
?
Size:25.4 x 25.4 x 11.0 mm
Isolation:1600 VDC
SW15:Down Load SW15 Series SPC.? ??SW15?Safety:????
15 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
4:1 Range:? 10 ~ 40 VDC
18 ~ 75 VDC
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:50.1 x 25.4 x 10.8 mm
Isolation:1600 VDC
ST15:Down Load ST15 Series SPC.? ??ST15?Safety:????
15 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
? 9 ~ 36 VDC
18 ~ 75 VDC
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:50.1 x 25.4 x 10.8 mm
Isolation:1600 VDC
ZB15:Down Load ZB15 Series SPC.? ??ZB15?Safety:????
20 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15
?
?
Size:25.4 x 25.4 x 11.0 mm
Isolation:1600 VDC
SW20:Down Load SW20 Series SPC.? ??SW20?Safety:????
20 W ? Series
2:1 Range:? 18 ~ 36 VDC
36 ~ 75 VDC
?
?Single: 2.5, 3.3, 5
?
?
Size:50.1 x 25.4 x 10.8 mm
Isolation:1600 VDC
ST20:Down Load ST20 Series SPC.? ??ST20?Safety:????
30 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 3.3, 5, 12, 15
?
?
Size:25.4 x 25.4 x 11.0 mm
Isolation:1600 VDC
SW30:Down Load SW30 Series SPC.?If you were interested in this new product, please don't be hesitated to?contact us. ??SW30?Safety:????
30 W ? Series
2:1 Range:? 18 ~ 36 VDC
36 ~ 75 VDC
?
?Single: 2.5, 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:50.8 x 25.4 x 11.0 mm
Isolation:1600 VDC
ST30:Down Load ST30 Series SPC.? ??ST30?Safety:????
30 W ? Series
4:1 Range:? 10 ~ 40 VDC
18 ~ 75 VDC
?
?Single: 2.5, 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?
Size:50.8 x 40.6 x 11.9 mm
Isolation:1600 VDC
SF30:Down Load SF30 Series SPC.? ??SF30?Safety:????
30 W ? Series
2:1 Range:? 36 ~ 75 VDC

?
?Single: 1.8, 2.5, 3.3, 5, 12, 15, 24
?
?
Size:50.8 x 40.6 x 11.9 mm
Isolation:1600 VDC
SK30:Down Load SK30 Series SPC.? ??SK30?Safety:????
40 W ? Series
2:1 Range:? 36 ~ 75 VDC

?
?Single: 1.8, 2.5, 3.3, 5, 12, 15, 24
?
?
Size:50.8 x 40.6 x 11.9 mm
Isolation:1600 VDC
SK40:Down Load SK40 Series SPC.? ??SK40?Safety:????
20 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
4:1 Range:? 10 ~ 40 VDC
18 ~ 75 VDC
?Single: 3.3, 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?Triple: 5/±12, 5/±15
Size:50.8 x 50.8 x 11.4 mm
Isolation:1600 VDC
SU20:Down Load SU20 Series SPC.? ??SU20?Safety:????
40 W ? Series
2:1 Range:? 9 ~ 18 VDC
18 ~ 36 VDC
36 ~ 75 VDC
?
?Single: 5, 12, 15, 24
?Dual: ±5, ±12, ±15
?Triple: 5/±12, 5/±15
Size:50.8 x 50.8 x 11.4 mm
Isolation:1600 VDC
SU40:Down Load SU40 Series SPC.? ??SU40?Safety:????
60 W ? Series
4:1 Range:? 9 ~ 36 VDC
18 ~ 75 VDC
?
?Single: 5, 12, 15, 24
?
?
Size:50.8 x 25.4 x 11.0 mm
Isolation:1600 VDC
ST60:Down Load ST60 Series SPC.?If you were interested in this new product, please don't be hesitated to?contact us. ??ST60?Safety:????


|关于我们|联系我们|
Copyrightby北京杰创宏达电子有限公司
